Progtech's simbols mini safe projector

Mini Safe Evo

Made in Italy
5 years warranty

The new led projectors line MINI SAFE is designed to ensure the safety of employees in work environments through an endless range of applications that can be achieved thanks to special lens systems that projects special shapes on the floor in green, red and blue color variants.

Installations

Description Mini Safe Evo

Compared to any other type of signalling system, such as applying adhesive, this system is clearly visible, even in brightly lighted environments or on surface always covered in dust and dirt. It’s the ideal product, for example, to report emergency exit directions (Mini Safe Arrows or Mid Safe Arrows) or sale collection point and hazardous areas (Safe Cross). Moreover, with the image of the walking man you can light up a pedestrian path and with the running man you can light up an emergency exit. A lot of standard symbols are available (ask the company for the symbol table) and it’s possible, on request, to customize the symbols. The lamp is made with a plastic structure and an aluminum heatsink completed with silicone gaskets which guarantee the IP54 degree of protection.

Codice Mini Safe Evo
Led Colour LampGreen, Red, Blue, Yellow
Power Supply90-305Vac / 50-60Hz
Maximum Power Input25W
SourceN°1 Blue Led, N°1 Yellow LED, N°1 Red Led, N°1 Green Led
Mini Safe Evo Symbol Lenght At 4mt height440mm
Dominant Wavelength525nm (green) 620nm (red) 460nm (blue) 580nm (yellow)
Operating TemperatureFrom -40°C To +50°C
ControlOn/Off
Photobiological Safety Risk GroupRG1
MaterialsAnodized aluminum and PVC (structure), Painted steel (bracket), Stainless steel (screws and cable glands), Glass (lenses), Silicone (gaskets)
IP Protection ClassIP54
Weight2,5 Kg
Packaging Dimensions150 mm (L) x 150 mm (W) x 220 mm (H)
Lamp Dimension110 mm (L) x 110 mm (W) x 190 mm (H)
Power Supply Dimension180 mm (L) x 63 mm (W) x 36 mm (H)
